- DESCRIPTION
CP6 is a double acting piston sealing element which consists of two parts: sealing ring of special profile with three edges and square ring R.
- ADVANTAGES
• Compactness
• High static and the dynamic sealing effect
• Resistance to twisting due to rectangular profile
• Simple groove design, possibility to use in the one-piece piston
• Big gaps are allowed
• High abrasion resistance- MATERIAL
Polyester TPE 47D
Square ring R - NBR- APPLICATION
• At big recurrence
• Agricultural machinery
• Construction machinery
• Material handling equipment
• Cylinders for industrial equipment with light and medium operating modes- CONDITIONS
• Temperature:
-50°С...+100°С
• Sliding speed
up to 0.5 m/s
• Operating pressure:
up to 30 MPa (at a temperature of 60°C)
• Media:
mineral oils, water-oil emulsions- NOTES
It is recommended to use with two piston guide rings in cylinders with the long stroke and with one guide ring in cylinders with the short stroke and under low radial loads.
